ONDU EIKAN 4x5" Standard

€980.00

          • Imagine a camera that grows with you. The EIKAN is the realization of that concept. For years, I had been envisioning a design for a large format camera. However, I hesitated to bring it to life because it didn't offer any innovative solutions to the problems I wanted to address. That is, until I developed the modular system of the ONDU EIKAN Camera range.

          •  This camera serves as the perfect gateway to large format photography, allowing you to continually improve and nurture your creative flow over time. Its modular design empowers you to make enhancements and adapt the camera to your evolving needs. Whether you're a beginner venturing into large format imagery or seeking a lightweight setup, the Standard ONDU Eikan set is the ideal camera to start your large format journey. All orders made after 15.12.2024 Have a lead time of 2-4 Weeks.


              • Foldable design for easy transport and storage with rear vertical vertical lock which when disabled allows for an extra 20° of rear tilt useful when shooting wide angle lenses.
              • Compatible with standard sheet film holders
              • Permanent magnets for secure attachment of the bellows and back
              • Graflock compatible with Lomograflok, and other graflock backs
              • Ground glass with a ground glass protector
              • Premium materials such as anodized aluminum and walnut wood for durability and unmatched design
              • Front zeroing locks
              • Zeroing indication for the bottom of the front standard
              • Precise focusing system with micro linear rails
              • Dimensions: 210x210x100mm (including knobs), actual body is 185mm square
              • Weight: Approximately 1500g stanard |  1600g Range | 1970g Panoramikku 4x10". Actual weights fluctuate 50g +/- due to the nature of materials used. ( final weight might vary by a slight margin as well due to possible future features of the camera. )
              • Standard extension 320mm - 420 with the added Extension back module
              • Possible to convert into a dedicated 4x10" camera.
              • Handcrafted out of European Walnut and cnc cut aircraft grade aluminium.

              Movements

              • Max Front Rise/Fall: 42mm / 40mm
              • Max Front Shift: 20mm
              • Max Front Swing: +/- 45º
              • Rear Tilt: + / - 20º
              • Max Front Tilt: +/- 45º
          • Exposure card




View full product details


ONDU EIKAN 4X5" RANGE

€1,250.00

          • Imagine a camera that grows with you. The EIKAN is the realization of that concept. For years, I had been envisioning a design for a large format camera. However, I hesitated to bring it to life because it didn't offer any innovative solutions to the problems I wanted to address. That is, until I developed the modular system of the ONDU EIKAN Camera range.

          • ONDU EIKAN 4x5" RANGE - shares almost all of the same features as the Standard with the exception of longer bellows and a rear sliding rail that enables the camera an extra 10cm or rear extension. This means that the total extension reaches all the way up to 420mm. Perfect for macro photography or longer focal length lenses. It weighs 1600g.

          • THE 4x5 CAMERAS are in production At the moment, expected stock around end January
          • .
              • 96x99 Lensboard size
              • Foldable design for easy transport and storage with rear vertical vertical lock which when disabled allows for an extra 20° of rear tilt useful when shooting wide angle lenses.
              • Compatible with standard sheet film holders
              • Permanent magnets for secure attachment of the bellows and back
              • Graflock compatible with Lomograflok, and other graflock backs
              • Ground glass with a ground glass protector
              • Premium anodized aluminum and walnut wood for durability and unmatched design
              • Front zeroing locks
              • Zeroing indication for the bottom of the front standard
              • Precise focusing system with micro linear rails
              • Dimensions: 210x210x100mm (including knobs), actual body is 185mm square
              • Weight: Approximately 1600g . Actual weights fluctuate 50g +/- due to the nature of materials used. ( final weight might vary by a slight margin as well due to possible future features of the camera. )
              • Max Bellows extension 420mm
              • Possible to convert into a dedicated 4x10" camera.
              • Handcrafted by ONDU in Slovenia out of European Walnut and cnc cut aircraft grade aluminium.

              Movements

              • Max Front Rise/Fall: 42mm / 40mm
              • Max Front Shift: 20mm
              • Max Front Swing: +/- 45º
              • Rear Tilt: + / - 20º
              • Max Front Tilt: +/- 45º
          • Exposure card








View full product details


ONDU EIKAN PANORAMIKKU 4X10"

€1,600.00

          • Imagine a camera that grows with you. The EIKAN is the realization of that concept. For years, I had been envisioning a design for a large format camera. However, I hesitated to bring it to life because it didn't offer any innovative solutions to the problems I wanted to address. That is, until I developed the modular system of the ONDU EIKAN Camera range.

          • ONDU EIKAN 4x10" Panoramikku - shares the same rear extension of the RANGE module with the addition of a new rear standard as well as a completely new bellows that fit the panoramic format. Weight of the camera is just under 2 kilos at 1970g.

          • All orders made after 30.10.2024  have a lead time of 4-8 weeks with expected shipping mid to end December!
              • 96x99 Lensboard size
              • Foldable design for easy transport and storage with rear vertical vertical lock which when disabled allows for an extra 20° of rear tilt useful when shooting wide angle lenses.
              • Compatible with standard sheet film holders
              • Permanent magnets for secure attachment of the bellows and back
              • Graflock compatible with Lomograflok, and other graflock backs
              • Ground glass with a ground glass protector
              • Premium anodized aluminum and walnut wood for durability and unmatched design
              • Front zeroing locks
              • Zeroing indication for the bottom of the front standard
              • Precise focusing system with micro linear rails
              • Dimensions: 343x210x100mm (including knobs), actual body is 320mm x185mm
              • Weight: 1970g Panoramikku 4x10". Actual weights fluctuate 50g +/- due to the nature of materials used. ( final weight might vary by a slight margin as well due to possible future features of the camera. )
              • Max bellows draw 420mm
              • Possible to convert into a 4x5" camera with the RANGE add-on. ( available soon )
              • Handcrafted by ONDU in Slovenia out of European Walnut and cnc cut aircraft grade aluminium.

              Movements

              • Max Front Rise/Fall: 42mm / 40mm
              • Max Front Shift: 20mm
              • Max Front Swing: +/- 45º
              • Rear Tilt: + / - 20º
              • Max Front Tilt: +/- 45º
          • Exposure card




View full product details

Last Batch of ONDU cameras

We recently announced that ONDU will cease pinhole cameras production for the foreseeable future (maybe indefinitely), to focus on other projects and products. This last batch is available now, some orders might take a few weeks to fulfill since some cameras are in the finishing stages of production. Thank you for your support over all of these years<3
